GL1402 is available in color and mono variants. GL1402 color features red, green, and blue rows with 14 µm gaps between each row to minimize color crosstalk. Read out speed is 27 kHz. GL1402 mono features a three row monochrome option with a read out speed of 27 kHz, or a one row monochrome option with a readout speed of 81 kHz. GL1402 has a 28.7 ke‾ full well capacity and a dynamic range of 70 dB. The sensor has a 12 bit ADC and 4 sLVDS channels, with the option to run slower at 2 or 1 sLVDS channel. GL1402 power consumption is less than 420 mW at maximum read out speed. The sensor is assembled into a 54 pin CLCC package with outer dimensions 38 x 7.4 mm.

GSPRINT4502 is a 2 Megapixel (2048 x 1216) 2/3 sized (10.7 mm) high speed, global shutter image sensor designed with the latest 4.5 μm charge domain global shutter pixel. It achieves more than 30k e¯ FWC, less than 4 e¯ rms read noise and > 68 dB dynamic range, optionally to be increased with multi-slope HDR mode. Using an advanced 65nm CIS process and light pipe technology, the sensor achieves >65% QE and more than 1/40,000 shutter efficiency. With on-chip charge binning, FWC can be further increased to > 120ke¯ and frame rate is quadrupled. GSPRINT4502 consists of 64 pairs sub-LVDS channels running at 1.2Gbps which delivers a stunning 3300 fps at 8 bit per pixel and full resolution and over 10000 fps with binning mode. These unique features make it an ideal solution for demanding imaging in applications such as 3D laser profiling, industrial inspection, motion analysis and high speed imaging.

GSPRINT4510 is a 10MP (4608 x 2176) 4/3” (22.9mm) high speed image sensor designed with the latest 4.5 µm charge domain global shutter pixel. It achieves more than 30 ke¯ charge capacity and less than 3 e¯ rms read noise. Using an advanced 65 nm CIS process with light pipe technology, the sensor achieves >67% QE and more than 1/40,000 shutter efficiency. With on-chip charge binning, full well capacity can be further increased and frame rate is almost quadrupled. GSPRINT4510 will be offered in two variants to support in the most optimal way different end-use use cases. One version is dedicated to 3D laser profiling and supports 144 pairs sub-LVDS channels running at 1.2Gbps each, which delivers a stunning 2000 fps in 8-bit operation at 2048 rows and > 3500 fps with an ROI of 1024 rows in combination with several HDR modes. Incorporating unique, tailored features such as a thinner glass lid to reduce stray light reflection, the option to have no micro lenses, and either a sealed or removable glass lid makes GSPRINT4510 the ideal solution for 3D laser scanning applications. For other applications including high-speed industrial inspection, life science imaging and 4K video applications, the sensor is offered in monochrome, color sensor configuration, and achieve up to 500 fps @ 12-bit, 1008 fps @ 10-bit and 1928 fps @ 8-bit with full resolution. On-chip 2×2 charge binning can boost frame rates more than x3 with a full well charge increase to 120 ke¯. Flexible output channel multiplex modes make it possible to reduce frame and data rate to make it compatible with all available camera interface options. This version of the sensor incorporates micro lenses on top of the pixels and a sealed glass lid making GSPRINT4510 the ultimate choice for many applications such as 4/3”(Micro Four Thirds) format global shutter cameras in slow motion capture or drone-mounted videography.

GSPRINT4521 is a 21 Megapixel (5120 x 4096) APS sized (29.5mm diameter) high speed, global shutter image sensor designed with the latest 4.5 μm charge domain global shutter pixel. It achieves 32 ke¯, less than 3 e¯ rms read noise and > 69 dB dynamic range, optionally increased to 81 dB with a dual gain HDR mode. Its state-of-the-art 65nm CIS process allows the sensor to use on-chip charge binning, further increasing FWC and almost quadrupling frame rate. GSPRINT4521 will be offered in two speed variants. The full speed variant consists of 160 pairs sub-LVDS channels running at 1.2Gbps which delivers a stunning 1000 fps in single gain operation at 8 bit per pixel and full resolution, and more than 3500 fps with a ROI of 1024 rows in a dedicated 3D laser profiling mode. These unique features make it an ideal solution for demanding imaging in high-end applications such as high speed 4K video, industrial inspection, motion analysis and life science imaging.

GSENSE4040BSI is a BSI CMOS image sensor of 16.8MP (4096 x 4096) resolution with 9 μm × 9 μm pixel size, and a photosensitive area of 36.8 mm x 36.8 mm (52 mm diagonal). Using dual gain HDR operation mode, 85 dB is achieved with 39k e¯ full well capacity and 2.3 e¯ readout noise. 18 pairs of LVDS channels running at 600 MHz per channel support full-resolution imaging at a frame rate of 24 fps. GSENSE4040BSI is assembled in 140-pin PGA ceramic package with a removable glass lid. This sensor is pin compatible with GSENSE4040FSI for fast and easy integration

GSENSE4040 is a 16.8Mega pixel resolution CMOS image sensor. Featured with five transistor (5T) HDR pixel design on a 9 μm pitch, the sensor could achieve 3.7 e‾ dark noise and 74 ke‾ FWC simultaneously in HDR mode. GSENSE4040’s maximum frame rate (will full resolution) is 24 fps in HDR mode. It supports 2 x 2 charge binning mode in which x 4 frame rate is achieved. These features make GSENSE4040 an ideal image sensor for various applications. GSENSE4040 is offered in two variations: CMN and CMT. CMN is a monochrome sensor without microlens array and protected by a removable glass lid, which is ideal for X-ray imaging, charged particle detection, and micro-CT application; while CMT is a monochrome sensor with microlens array and sealed with D263<sup class="xiao">®</sup> T lids with anti-reflective coating on both sides, ideal for medical imaging and astronomy applications.
