Gpixel introduces GLUX backside illuminated sCMOS product family with 0.8 e- noise and CSI-2 MIPI interface for cost-effective ultra-low light imaging.

date:2021-03-12

12th March, 2021, Changchun, China – Gpixel presents GLUX9701BSI, a 1” sized, high sensitivity BSI sCMOS image sensor with a resolution of 1.3 MP (1280 x 1024) and large 9.76 μm x 9.76 μm pixels. The sensor is the first in a new family targeting extreme low-light imaging for both surveillance and scientific use. Enhanced low noise technology combined with best-in-class BSI QE enables video in starlight conditions or low-light scientific imaging at high frame rates.


GLUX9701BSI supports a dual-gain HDR mode, achieving dynamic range of 90 dB by combining 1.5 e– RMS read noise and 50 ke– full well charge. A dedicated low noise mode further optimizes imaging performance with read noise of 0.8 e– and power consumption of only 180 mW. Dedicated circuit and process engineering improves noise uniformity of GLUX significantly over previous sCMOS models with a close to Gaussian noise distribution behavior as can be seen in below figure.

Noise-GS2020BSI-9701BSI-1-1024x576.pngNoise-GS2020BSI-9701BSI-1-1024x576.pngNoise-GS2020BSI-9701BSI-1-1024x576.pngNoise-GS2020BSI-9701BSI-1-1024x576.pngNoise-GS2020BSI-9701BSI-1-1024x576.png


The sensor offers two types of data output: 4 channel sub-LVDS and MIPI (CSI-2, D-PHY). The default frame rate at HDR of 30 fps can be achieved using both channel options with dedicated operation modes achieving frame rates of up to 120 fps. Various operating functions are available including master mode, slave mode, and standby mode.


GLUX9701BSI is assembled in an 84-pin CLCC package with compact outer dimensions of 22 mm x 22 mm. Both removable and sealed glass lid variants are available as standard options.


Figure below shows low light image comparison between GLUX9701BSI (left) and GSENSE2020BSI (right), both at 25 fps with <0.01 lux light intensity (measurement equipment limited).


First engineering samples and evaluation boards will be available at starting April, 2021. Please contact info@gpixel.com or visit our website products page https://www.gpixel.com/products/ for more information.


About GLUX sensor family

The GLUX family is a new Gpixel BSI sCMOS image sensor series combining sub-electron noise performance with high frame rates for ultra-low light imaging addressing needs in both scientific and surveillance applications. For more information about the GLUX product family roadmap, please contact info@gpixel.com.


About Gpixel

Gpixel provides high-end customized and off-the-shelf CMOS image sensors for industrial, medical, and scientific applications. Gpixel’s standard products include the GMAX and GSPRINT global shutter, fast frame rate sensors, the GSENSE and GLUX high-end scientific CMOS image sensor series, the GL series of line scan imagers, and the GLT series of TDI imagers. Gpixel’s broad portfolio of products utilizes the latest technologies to meet the ever-growing demands of the professional imaging market.
