September 29th 2021, Changchun, China – Gpixel expands the GMAX product family of global shutter image sensors with the 152 MP GMAX32152, the highest resolution global shutter image sensor commercially available in the market.

This latest GMAX sensor incorporates a 3.2 µm charge domain global shutter pixel in a 16556 (H) x 9200 (V) array for an imaging area of 53 mm x 29.4 mm (60.6 mm diagonal). The 1.8:1 wide aspect ratio optimizes the inspection of flat panel displays of similar format and increases the efficiency of large field of view aerial mapping applications.

GMAX32152 shares a common pixel and read-out architecture with the 103 MP GMAX32103, achieving the same full well capacity of 9.4 ke- and a read noise of 4 e- for a dynamic range of 67.6 dB.

The read out of image data is accomplished using 38 pairs of sub-LVDS channels each operating at 960 MHz delivering a full resolution frame rate of 16 fps at 12bit output and total aggregate data rate of 36.48 Gbps. Flexible output multiplexing options and functions are available to customize the data output for different imaging systems and applications.

GMAX32152 is assembled in a 183-pin µPGA ceramic package with outer size 68.2 mm x 52 mm. An anti-reflection coating is applied to both sides of the glass lid to optimize sensitivity.

This sensor is provided in monochrome and RGB Bayer color options. Monochrome and RGB color engineering samples can be ordered today for delivery in October, production release is expected by mid 2022. For more information, please visit the product page or contact info@gpixel.com.

Gpixel will demonstrate the GMAX32152 with live demo at the Vision Stuttgart exhibition held at the Messe Stuttgart, Germany from October 5-7 2021. Please pay us a visit at booth 8B40 (hall 8).

Below picture taken with GMAX32152. Bottom is full resolution of 152MP, top left digital zoom to 5MP, top right digital zoom to 1MP.

About GMAX sensor family
The GMAX series is Gpixel’s global shutter product family, including the 26 MP 1.1” GMAX0505 image sensor and its lower resolution pin compatible variants GMAX2505, GMAX2509, and GMAX2518, in addition to the APS-H format 65 MP GMAX3265 sensor, the full frame 51 MP GMAX4651 sensor, medium sized 103 MP GMAX32103, and the 152 MP GMAX32152.
